Laminated glass repair

Professional repair system for repairing laminated glass.

  • The tool case contains all tools that are required for a professional laminated glass repair on passenger and commercial vehicles.
  • Simple and economic handling
  • Very high professional quality
  • Enables the professional repair of damaged laminated glass panes

Consisting of:

  • 1 x Repair bridge with injector holder
  • 1 x grindingand polishing paste
  • 1 x inspection mirror with sucker
  • 1x UV lamp 6 W, 230 V / 50 Hz
  • 1 x mini drill with 230 V mains adapter
  • 1 x carbide metal rod
  • 1 x pen-light incl. batteries
  • 1 x lighter with child safety device
  • 1 x small parts box with 3 plastic injectors
  • 1 repair resin - 5 ml
  • 1 size resin - 5 ml
  • 20 Mylar squares
  • 5 doctor blades
  • 1 carbide drill bit conical 1.0 mm
  • 1 carbide drill bit round 1.2 mm
  • operating instructions

Supplied in a sturdy plastic casewith molded foam-lined interior.

Laminated Glass Repair System Case,Truck/Car

Professional system for repairing laminated glass.The toolbox contains all tools and equipment needed for professional laminated glass repair on commercial motor vehicles and passenger vehicles. The individual tools are all of high quality and extremely durable. The positive and negative pressure required for repairs is generated on the system by a pressure/vacuum pump.

The simple layout of the system ensures safe and easy operation. Thanks to the extremely thin, high-qualityrepair resin, even the smallest cracks are filled reliably. Even stone chip damage with splinters or dirty impact points can be repaired perfectly – the system also includes a cordless mini drill for drilling out the impact point.

The seal on the large resin chamber has an inner diameterof 9.5 mm, and is thus suitable for large-scales tone chip damage as seen regularly on HGVs and buses. The large resin chamber is also ideal for repairing stone chip damage with two impact points in close proximity to each other. The resin chamber is designed so that it can be used on both flat and upright glass panes.

The 125 mm suction cup on the base unit is fixed securely in place with only a few pumps from the vacuum pump.

The stable lightweight alloy arm can be moved and pivoted so that the resin chamber can be positioned exactly and easily over the impact point.

Consisting of:

  • Large resin chamber, 3/8”
  • Small resin chamber, 3/16”
  • Connecting hose
  • Pressure/vacuum pump
  • Holder with suction cup for pump
  • Inspection mirror with suction cup
  • UV lamp, 6 W, 230 V / 50 Hz
  • Cordless mini drill, 9.6 V
  • Stud pin
  • Cracker
  • Light pen, incl. batteries
  • Lighter with child lock
  • 2 x repair resin, 5 ml
  • 1 x size resin, 15 ml
  • 1 x Polish for Stone Chips, 25 ml
  • 1 x stand magnifier, 15x
  • Box for small parts with following contents:
    • 3 x hypodermic syringes
    • 3 x needles
    • 20 x Mylar foil squares
    • 10 x doctor blades
    • 5 x injector seals, 3/8”
    • 5 x injector seals, 3/16”
    • 1 x carbide drill bit, conical, 0.8 mm
    • 1 x carbide drill bit, conical, 1.0 mm
    • 1 x carbide drill bit, round, 1.0 mm
    • 1 x carbide drill bit, round, 1.2 mm
    • Sanding and polishing set, 12 pcs.
    • Stone chip simulator
    • Detailed operating instructions


Supplied in a sturdy plastic casewith molded foam-lined interior.
